Back to the future: of web development

Back to the future:

of web development

Una Kravets ♥ una.im
Google Chrome DevRel

I ♥ CSS

CSS and HTML are getting much more powerful

"I'm from the future"

⚠️ NEW STUFF ⚠️

"Roads? Where we're going, we don't need roads. - Doc"

A note on browser support:

Standards-track APIs

<select name="version-select" id="version-select"
  <button>
    <selectedcontent></selectedcontent>
  </button>
  <option value="core">
    <div class="icon">
      <span class="material-symbols">hub</span>
    </div>
    <div class="meta">
      <div class="title">UnAI Core</div>
      <div class="subtitle">Balanced speed...</div>
    </div>
  </option>
  <option value="max">
  ...

<div class="comments">
  <a interestfor="commenters" href="#">
    24 comments
  </a>
</div>

<div id="commenters" popover="hint">
  <ul>
    <li>Jenny Smith</li>
    <li>...</li>
  </ul>
</div>

<div class="star-rating" data-rating="1.8">
  <figure></figure>
</div>

.star-rating {
  --percent-fill: calc(attr(data-rating type(<number>)) * 20%);

  figure {
    /*  hard breakpoint gradient background  */
    background:
        linear-gradient(to right,
        gold var(--percent-fill),
        transparent var(--percent-fill));

    /*  star mask  */
  }

  &::after {
    content: attr(data-rating);
  }
}
The most exciting things happening in web development right now are happening in CSS & HTML.
The best way to level up your web development skillset is to know what's possbile with modern UI capabilities.

Why care about CSS & UI?

  1. 🧮 Separate logic and styling
  2. 🗑️ Reduce 3P dependancies
  3. 🏗️ Reduce maintenance costs & complexity
  4. ⌨️ Make it easier to build accessible interfaces
  5. 🚀 Better performance off the main thread
  6. 🧖🏻‍♂️ Build faster, make your life easier

Built-in syntax highlighting

  • No heavy libraries
  • No added span tags
  • Supports textarea & dynamic editing
blog.glyphdrawing.club

Let's go on an adventure...

Customizable select

Layered UI

No-JS carousel

Customizable select

Recipe:

  1. Customizable select menu
  2. Scroll-driven animation
  3. CSS trigonometric functions
  4. Registered custom properties
  5. Bonus: CSS carousel markers

Customizable select

select,
select::picker(select) {
  appearance: base-select;
}
Option One Option One Option Two Option Three Option Four Option Five <select> <selectedcontent> ::picker(select) <option>::checkmark <option>:checked <option> <select>::picker-icon
<select name="version-select" id="version-select"
  <button>
    <selectedcontent></selectedcontent>
  </button>
  <option value="core">
    <div class="icon">
      <span class="material-symbols">hub</span>
    </div>
    <div class="meta">
      <div class="title">UnAI Core</div>
      <div class="subtitle">Balanced speed...</div>
    </div>
  </option>
  <option value="max">
  ...

selectedcontent .subtitle,
selectedcontent .icon {
  display: none;
}

--rad: calc(var(--btn-size) + var(--gap));
background-color: var(--bg);
transform: translate(
  calc(cos(var(--angle)) * var(--rad)), /* x */
  calc(sin(var(--angle)) * var(--rad))); /* y */
transition: transform 0.3s var(--delay) ease;

.item:nth-child(1) {
  --bg: pink;
  --angle: 0deg;
  --delay: 0s;
}

.item:nth-child(2) {
  --bg: thistle;
  --angle: -45deg;
  --delay: 0.1s;
}

.item:nth-child(3) {
  --bg:	paleturquoise;
  --angle: -90deg;
  --delay: 0.2s;
}

...

.item {
  --radius: calc(var(--btn-size) + var(--gap));
  --angle: calc((sibling-index() - 1) * -45deg);
  --delay: calc((sibling-index() - 1) * 0.1s);
  background: hsl(calc(sibling-index() * 40), 70%, 80%);
  transform:
    translate(
      calc(cos(var(--angle)) * var(--radius)),
      calc(sin(var(--angle)) * var(--radius))
    );
  transition: transform 0.3s var(--delay) ease;
}

@function --radial-coord(--a, --rad) {
  result: translate(
    calc(cos(var(--a)) * var(--rad)),
    calc(sin(var(--a)) * var(--rad))
  );
}

.item {
  --radius: calc(var(--btn-size) + var(--extra-space));
  --delay: calc((sibling-index() - 1) * 0.1s);
  --angle: calc((sibling-index() - 1) * -45deg);
  transform: --radial-coord(var(--angle), var(--radius));
  background: hsl(calc(sibling-index() * 40), 70%, 80%);
  transition: transform 0.3s var(--delay) ease;
}

Scroll-driven animations

@keyframes appear {
  from {
    opacity: 0;
    transform: translate(0px, 50px);
  }

  to {
    opacity: 1;
    transform: translate(0px, 0px);
  }
}

li {
  animation: appear linear both;
  animation-timeline: view();
  animation-range: entry 0 cover 25%;
}

Progressive enhancement 💜💜💜

@supports (animation-timeline: scroll()) {
  html {
    scroll-timeline-name: --root-scroll;
  }

  @keyframes fade-in {
    from {
      opacity: 0;
      display: none;
    }
    to {
      opacity: 1;
      display: block;
    }
  }

  a {
    animation: fade-in auto linear both;
    animation-timeline: --root-scroll;
    animation-range: 20% 30%;
  }
}
Carousel scroll-markers

Layered UI

Recipe:

  1. Anchor positioning
  2. Repositioning logic
  3. Popover=hint
  4. Interest invokers
<button popovertarget="my-tooltip">
  <p aria-hidden="true">?</p>
  <p class="sr-only">Open Tooltip</p>
</button>

<div id="my-tooltip" class="tooltip" popover>
  <p>I am a tooltip with more information.<p>
</div>

#my-tooltip {
  inset: auto;
  position-area: top;
  position-try: flip-block;
}
anchor-tool.com
.tooltip {
  container-type: anchored;

  /*  arrow  */
  &::before {
    content: '';
    top: 100%;
    left: 50%;
    border: solid transparent;
    border-top-color: var(--tooltip-bg);
    ...

    @container anchored(fallback: flip-block) {
      bottom: 100%;
      top: calc(-2 * var(--spacer));
      border-top-color: transparent;
      border-bottom-color: var(--tooltip-bg);
    }
  }
 <!-- Invoker -->
<button popovertarget="my-tooltip">
  <p aria-hidden="true">?</p>
  <p class="sr-only">Open Tooltip</p>
</button>

<!-- Popover -->
<div id="my-tooltip" class="tooltip" popover>
  <p>Lavender and fuchsia danced...</p>
</div>
 <!-- Invoker -->
<button interestfor="my-tooltip">
  <p aria-hidden="true">?</p>
  <p class="sr-only">Open Tooltip</p>
</button>

<!-- Popover -->
<div id="my-tooltip" class="tooltip" popover>
  <p>Lavender and fuchsia danced...</p>
</div>

🌶️ Interest Invokers 🌶️

<p>Hi! My name is <a href="https://una.im"
  interestfor="--una">Una Kravets</a>.
I'm a CSS and UI enthusiast...</p>

<div id="--una" popover="hint">
  <header>
    <picture>
      <img src="una.jpg" alt="Una">
    </picture>
    <div>
      <h2>una</h2>
      <a href="https://una.im">una.im</a>
    </div>
    <button>Follow</button>
  </header>
</div>

[interestfor] {
  interest-delay-start: 0.3s;
}

.parent:has(:interest-source) [interestfor] {
  interest-delay-start: 0s;
}

Protip from Emil Kowalski —>

popover=auto popover=manual popover=hint
Light dismiss (via click-away or esc key) ✅ Yes 🚫 No ✅ Yes
Closes other popover=auto elements when opened ✅ Yes 🚫 No 🚫 No
Closes other popover=hint elements when opened ✅ Yes 🚫 No ✅ Yes
Closes other popover=manual elements when opened 🚫 No 🚫 No 🚫 No
Can open and close popover with JS (showPopover() or hidePopover()) ✅ Yes ✅ Yes ✅ Yes
Default focus management for next tab stop ✅ Yes ✅ Yes ✅ Yes
Can hide or toggle with popovertargetaction ✅ Yes ✅ Yes ✅ Yes
Can open within parent popover to keep parent open ✅ Yes ✅ Yes ✅ Yes

[interestfor] Polyfill

import interestfor from "https://esm.sh/interestfor";

[interestfor] {
  /*  for polyfill this must be a custom property */
  --interest-delay-start: 0.1s;
  --interest-delay-end: 0.1s;
  interest-delay-start: var(--interest-delay-start);
  interest-delay-end: var(--interest-delay-end);
}

No-JS Carousel

Recipe:

  1. Scroll-snapping
  2. Scroll buttons
  3. Scroll markers
  4. Scroll-state queries
  5. Anchor positioning

CSS Carousels are just fancy scrollers.


<ul class="carousel">
  <li>...</li>
  <li>...</li>
  <li>...</li>
</ul>

.carousel {
  overflow-x: auto;
  scroll-snap-type: x mandatory;
  scroll-behavior: smooth;
}

Now with buttons!

.carousel {
  &::scroll-button(*) {
    position: fixed;
    position-anchor: --carousel;
    font-family: "Material Symbols Outlined";
  }

  &::scroll-button(right) {
    position-area: inline-end center;
    content: "arrow_forward_ios" / "Scroll Right";
  }

  &::scroll-button(left) {
    position-area: inline-start center;
    content: "arrow_back_ios" / "Scroll Left";
  }
}

And markers!

.carousel {
  scroll-marker-group: after;

  &::scroll-marker-group {
    position: fixed;
    position-anchor: --carousel;
    display: grid;
    ...
  }

  ::scroll-marker {
    content: counter(day-num);
    aspect-ratio: 1 / 1;
    ...
  }

  ::scroll-marker:target-current {
    transform: translateY(-0.5rem);
  }
}
chrome.dev/carousel-configurator
li {
  container-type: scroll-state;
  scroll-snap-align: center;

  div {
    scale: 0.8;
    transition: scale 0.3s ease;

    @container scroll-state(snapped: x) {
      scale: 1;
    }
  }
}

.day-card {
  & .meta {
    transform: translateY(calc(100% - 3rem));

    @container scroll-state(snapped: x) {
      transform: translateY(0);
    }
  }
}

::scroll-marker:target-current {
  anchor-name: --active-target;
}

.indicator {
  position-anchor: --active-target;
  inset: anchor(inside);
  margin-top: anchor-size();
  transition: inset 0.5s linear;
}

.follower {
  /*  anchor the follower element  */
  position: fixed;
  position-anchor: --hovered;
}

.possible-anchor:hover {
  /*  update the active anchor  */
  anchor-name: --hovered;
}

Multi-anchors!

1. Dynamic re-targetting for "bubble"

2. Ephemeral tooltips using:

position-area

position-try-fallbacks

popover=hint

[interestfor]

(Touch of JS to preserve active state since we're
re-anchoring with :hover)

Bring your own scroll markers with
scroll-target-group: auto

<ul class="parent">
  <li><a href="#intro">Introduction</a></li>
  <li><a href="#one">Section one</a></li>
</ul>

<div id="intro">Introduction</div>
<div id="one">Section one</div>

.parent {
  scroll-target-group: auto;
}

:target-current {
  /* styles for active anchor */
}

Anyway, there's a lot of new CSS stuff

  • if()
  • shape()
  • Range container queries
  • VIEW TRANSITIONS
/* Show only one of two */
#feedback-form, .open #feedback-btn {
  display: none;
}

/* Give both the same v-t-name, because */
/* we want to morph the one into the other */
#feedback-form, #feedback-btn {
  view-transition-name: --feedback;
}

/* Capture the parent as a separate layer, */
/* so it animates too */
#parent {
  view-transition-name: --feedback-parent;
}

...

This entire slide framework is built with Zero JavaScript

  • <style contenteditable>
  • font-family: 'FontWithASyntaxHighlighter'
  • ::scroll-button(*)
  • ::scroll-marker & :target-current
  • scroll-behavior: smooth
  • @container scroll-state(snapped: x) {}
  • sibling-index()

That's a lot of CSS

Do I need to know all the things?

Reach for native-first

universal APIs

no dependancies

The best way to level up your web development skillset is to get good at CSS and HTML
Leverage the power of the browser

Write once, works everywhere.

Raise your expectations for the web platform.

Stay in the know 👀

Personal

  • Twitter: @una
  • Blusesky: una.im
  • Website: una.im (RSS)

Chrome DevRel

  • New: developer.chrome.com
  • Stable features: web.dev
@una.im
